Stage : prefered dimensions :

6mx4m available

drum riser prefered

minimum 240x160 cm

​

At least 5 distribution boxes with 4 outlets, 220V:16A

Behind the guitar amps are 2 lightboxes with the band logo

​

Monitors / Monitor outputs : preferably 5, in order of importance

1 at Lead Vocal Position

2 at Drum Kit

3 XLR towards keyboard (has own monitoring system)

4 at Lead Guitar

5 at Bass. If 5 = not possible, shared position with 4

Changeover time : at least 30 minutes, preferably 45

​

While drums and keyboards are being set up, we like it if we can already set up the monitoring for the vocals, and adapt the rest of the instrument settings to that.

Downloadables

Stage Plan (PDF)

Stage Plan in PDF

  • 1 BD
  • 2 SNR
  • 3 12” Tom
  • 4 13” Tom
  • 5 14” Tom
  • 6 16” Floor
  • 7 18” Floor
  • 8 Hi Hat
  • 9 Ride
  • 10 OH L
  • 11 OH R
  • 12 Bass - DI from pedal board
  • 13 - 14 Keyboards from submix XLR
  • 15-16 Guitar  Geert 2 XLR
  • 17 Lead Vocals
  • 18 Backing Vocals Geert
  • 1 9Backing Vocals Wilfried
  • 20 Backing Vocals Sjoerd

BTL logo, banner, fonts in AI, EPS, jpg

beyond.the.labyrinth(at)telenet.be +32 497 53 95 79
